DT-250P
110V/220V dual-voltage input, portable and convenient for on-site work.
High-efficiency inverter design with over-temperature, overload, and VRD protection for enhanced safety.
Supports MMA welding, high/low pulse, and multi-level adjustable arc force for versatile applications.
Real-time voltage and current display for accurate monitoring and adjustment.
Specifications
| Input Power | V | 110Ｖ,1Φ | Pre flow time | Sec | 0.03, 0.04, 0.07 |
| 220Ｖ,1Φ | Post flow time | Sec | 1.5, 3 | ||
| Input voltage range | % | ±15% | Pulse current | A | - |
| Input frequency | HZ | 50&60 | Pulse frequency | HZ | High：10 |
| Rated input capacity | KVA | 11.73 | - | ||
| KW | 6.93 | Low：1 | |||
| Rated output | V | TIG：18 | Pulse Ratio Width | % | 50 |
| STICK：26 | Duty cycle | - | 250A / 20% | ||
| A | TIG：250 | 112A / 100% | |||
| STICK：150 | Water cooler control | - | - | ||
| Welding amperage range | A | TIG：5~250 | Cleam | - | - |
| STICK：5~150 | Gas check | - | - | ||
| Efficiency | % | 72 | Crater control | - | - |
| Open-circuit voltage | V | 105±5 | Insulation class | - | H |
| Up slope | Sec | - | Protection class | - | IP21S |
| Down slope | Sec | - | Dimension (W*D*H) | mm | 195*450*280 |
| Spot time | Sec | - | Net Weight | kg | 11.8 |
